Brand ASROCK
Model NUC BOX-1165G7
Processor Details i7-1165G7, QC, Max Speed up to 4.7GHzi
Chipset MCP
BIOS AMI SPI 256 Mbit
Technology Dual Channel DDR4 3200 MHz
Capacity 64GB (32 GB per DIMM)
Socket 2 x 260-pin SO-DIMM
Controller Intel® Iris® Xe Graphics
HDMI 1 x HDMI 2.0a
DisplayPort 1 x DP 1.4
MultiDisplay Quad-Display (Included 2 outputs from Type-C)
M.2 1 x M.2 (KEY M, 2242/2260/2280) with PCIe x4 and SATA3 for SSD
WLAN 1 x Intel® Wi-Fi 6 AX200 module
Interface Realtek ALC233, High Definition Audio.
Controller/ Speed LAN1: Intel® I219V with 10/100/1000 Mbps
LAN2: Intel® I225LM with 10/100/1000/2500 Mbps
Connector 2 x RJ-45
USB 2 x USB 3.2 Gen2 (Type-A)
Audio 1 (headphone & microphone jack)
Ethernet 1 x 1 Gigabit LAN, 1 x 2.5 Gigabit LAN
DC Jack 1
SATA 1 x SATA3.0 (6.0 Gb/s)
Mounting VESA mounting
OS Support Windows 10
Packing List 1 x 19V/90W Power Adapter
1 x Screw Package
1 x VESA mounting bracket
Gift Package 2 x SCREW M2*2,D=5 (13G020302034AK)
1 x NUT M2 H=3.35mm (13G020271010AK)
1 x AC PWR CORD (14G110000212AK)
1 x NUC BOX-TGL SERIES QIG (15G06M098000AI)
CPU Brand Intel
CPU Socket N/A
Memory Slots 2
Maximum Memory Supported 260-pin SO-DIMM
Storage 1 x M.2 (KEY M, 2242/2260/2280) with PCIe x4 and SATA3 for SSD
Desktop Form Factor Mini PC
Product Condition New
CPU i7-1165G7
